Designed for optimal performance, the dual-processor SuperServer 6046 series support the QPI format quad-core/dual-core Xeon 5600/5500 Series processors in a high-density 4U form-factor. The 6046 SuperServer has excellent expansion capability and feature set with 7-year lifecycle. It is ideal for embedded/IPC environments.
- General Information
- Manufacturer
- Supermicro Computer, Inc
- Manufacturer Website Address
- http://www.supermicro.com
- Brand Name
- Supermicro
- Product Line
- SuperServer
- Product Type
- Server Barebone System
- Warranty
- Limited Warranty
- 3 Year
- Processor
- Number of Processors Supported
- 2
- Processor Socket
- Socket B LGA-1366
- Processor Supported
- Xeon
- QuickPath Interconnect Supported
- Yes
- QuickPath Interconnect
- 6.40 GT/s
- 64-bit Processing
- Yes
- Chipset
- Chipset Manufacturer
- Intel
- Chipset Model
- 5520
- Memory
- Maximum Memory Supported
- 192 GB
- Memory Technology
- DDR3 SDRAM
- Memory Standard
- DDR3-1333/PC3-10600
- Total Number of Memory Slots
- 12
- Controllers
- Controller Type
- Serial ATA/300
- RAID Supported
- Yes
- Display & Graphics
- Graphics Controller Model
- G200eW
- Graphics Memory Capacity
- 16 MB
- Graphics Memory Technology
- DDR2 SDRAM
- Network & Communication
- Ethernet Technology
- Gigabit Ethernet
- I/O Expansions
- Number of External 5.25" Bays
- 3
- Number of 3.5" Bays
- 5
- Total Number of Expansion Slots
- 6
- Number of PCI Express x4 Slots
- 2
- Number of PCI Express x8 Slots
- 4
- Interfaces/Ports
- Total Number of USB Ports
- 8
- Number of USB 2.0 Ports
- 8
- Network (RJ-45)
- Yes
- VGA
- Yes
- Number of SATA Interfaces
- 6
- Power Description
- Input Voltage
- 110 V AC
- 220 V AC
- Number of Power Supplies Installed
- 1
- Maximum Power Supply Wattage
- 865 W
- Physical Characteristics
- Color Family
- Black
- Product Color
- Black
- Form Factor
- Tower
- Rack Height
- 4U
- Height
- 7"
- Width
- 17.2"
- Depth
- 20.5"
- Weight (Approximate)
- 35 lb
- Miscellaneous
- Package Contents
- SuperServer 6046T-TUF Barebone System
- 1 x Super X8DTE-F Motherboard
- 1 x 4U Chassis
- 1 x 4U SC842 5x3.5inch Hotswap SAS/SATA with SES2
- 5 x SATA CABLE 61CM FLAT S-S PBF
- 2 x 8pin to 8pin ribbon cable with tube for SGPIO, 40cm, PBF
- 1 x CD For X8 series
- 1 x 865W PS2 POWER SUPPLY W/2 8CM FANS
- 1 x Front ctrl cable 16 pin split, 6" , PBF (with converter head)
- 1 x Front ctrl cable ROUND 16 TO 16 PIN RIBBON 20"( 50cm)
- 2 x 4 to 4 pin rear fan pwr ext w/ square header, 30cm (PWM)
- 1 x 57CM, 4 PIN MIDDLE FAN POWER EXTENSION (PWM)
- 2 x 80x38 4 pin PWM fan assembly for SC743, 745
- Additional Information
Storage Controller Detail:
- Serial ATA Controller supports RAID 0, 1, 10 for Linux
- Serial ATA Controller supports RAID 0, 1, 5, 10 for Windows
- Certifications & Standards
- PCI 2.2
- ACPI up to 3.0
- Environmentally Friendly
- Yes
